Product Details:
|
| Warranty: | 1 Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
|---|---|---|---|
| Condition: | New | Use: | Automatic Milking System |
| Type: | Automatic Herringbone Structure | Voltage: | 380V/50Hz(three Phase) |
| High Light: | Parallel Cow Milking Parlor,Quick Release Cow Milking Parlor,Parallel automated milking parlour |
||
1.parallel manufacturer cow automatic sheep goat milking parlor machine equipment for big farm One fixed type milking system, each unit is separated and flexible;
2. There is a stand column, fixed frame and adjustable arch at each end of the cow place.
3. There is a carriage in every two cow places, fixing is easy and convenient, choosing different automation degree of guardrail.
4. The groove edge is made of stainless steel or galvanized plates, fixed by bolts or cement.
5. Door system: manual control, vacuum drive and pneumatically drive.
| Model | 9JY-2*8 | 9JY-2*12 | 9JY-2*16 | 9JY-2*20 |
| Working Vacuum | 50Kpa | 50Kpa | 50Kpa | 50Kpa |
| Pulsation Ratio | 60/40 | 60/40 | 60/40 | 60/40 |
| Frequency | 60 ± 3 RPM | 60 ± 3 RPM | 60 ± 3 RPM | 60 ± 3 RPM |
| Vacuum pump power | 5.5 KW | 2*4 KW | 2*4 KW | 2*5.5 KW |
| Vacuum pump speed | 2300L/min | 2*1400L/min | 2*1400L/min | 2*2300L/min |
| Milk pump speed | 8T/h | 20T/h | 20T/h | 20T/h |
| Milk pump power | 2.2KW | 4KW | 4KW | 4KW |
1.The inner pipeline of milking system is thoroughly cleaned
2. Bacterial content be reduced and milk is not easily to go bad.
3.The milking parlor makes the clean for main pipeline’s inner easily
4.Achieve the purpose of recycling the residual milk attached to the main pipeline.
5.KLN new modern design cow herringbone automatic milking parlor machine for sale saves water and electricity.
1. With ISO9001:2000, ISO9001:2008 certificate
2. With good quality and reasonable price
3. With all lifelong technical support.
4. Engineers overseas available to install the parlor and train the workers.
1. Milking parlor is mainly used for adult cows to milking.
2. Suitable for large and medium sized farm or milk collection station to provide advanced milking equipment.
3. Milking parlor used for all kinds of animals, like milking cow, goat, sheep and donkey.
Milking machine installation:
1) When you receive the milking parlor, we will send two engineers to your farm to guide installation, adjust the whole system and train labors within 7~10 days.
2) As the buyer, you need to bear the cost include actual expenses of round-trip tickets, insurance, accommodation and labor of engineers.
3)Tools for installation should be provided by the buyer, and we will provide detailed tool list for you.
cow head lock:
To provide a place to rest, to regulate the rest of the cattle position. According to the size of a variety of customized cattle, galvanized steel pipe and stewing. The site of concrete casting fixed, cow neck rail with the cow's horizontal bar to regulate the position of the cow in the horizontal bar.
milk cooling tank:
Milk cooling tank is the main supporting equipment for mechanized milking in the pasture, which is more suitable for manual milking in the pasture and milk collection station, and the dairy plant to cool and store fresh milk. Mainly used for cooling, storage of fresh milk, but also cooling, storage of other liquid materials. Straight wall cooling large area, through the automatic control system, one pace reachs the designated position observation operation, cause the cold milk quickly dropped to the required temperature constant temperature and renewal. Prevent bacterial reproduction, maintain the original state.
Our company is a production milking machine and other ranch supporting products, and machine research and development, production, sales, installation services as one of the professional companies.Products have been standing in the forefront of the world's advanced technology, combined with user demand, integration of international resources.The main products are 9J series milking parlor equipment (quick release type, fish bone/mid position type, ranch management);9J series rotary vane vacuum pump/piston mobile milking cart;9JL series full diet feed mixer;9L series refrigerating tank;9FL solid liquid separator for livestock manure;XP series rotary vane vacuum pump.Our company has always been in accordance with the production of first-class products, to meet the needs of users for the purpose of quality products and services to compete in the market, has achieved good social and economic benefits, won the satisfaction of users.
1. Every order should use a WHOLE container to put goods, as the milking parlor have too many parts.
2. A milk cooling tank is good for you to buy along with the milking parlor together in order to save installation fee for you.
3. After you received all parts for milking parlor, pay attention to put all parts into one room to avoid missing.
Certifications :
We have CE and ISO9001 certification for milking machine and related farm equipment.
Exhibition:We participate in the exhibitions in India and Russia every year.Welcome to negotiate.
